PSM 1000 – 2000












PSM 1000 – 2000
The Darley PSM 2000 GPM pump is the most compact, durable, and efficient 2000 GPM pump on the market. PSM Pump is NFPA rated to 2000 GPM, but this pump is capable of flows well over 2200 GPM. Not only will this meet customer demands, but it is also backed by Darley’s 10-year warranty on parts with 3 years of labor coverage! Experts in fluid dynamics technology have designed the pump. It utilizes an industry-best silicone carbide mechanical seal which handles use and misuses better than the seals your department has become accustomed to replacing in other pumps. The gearbox will handle 19,230 ft. lbs. of torque, and gears are helically cut to ensure quiet operation. Our impeller is vacuum cast eliminating porosity, and dynamically balanced to ensure smooth operation while spinning at over 4000 RPM. Pumps are modularly built for easy service, but if taken care of, this pump will last much longer than the chassis. This pump is built to last and is backed by the industry’s best service and engineering teams.
PSM 1000
- 1000 gpm (3785 L/M) @ 150 psi (10.3 bar)
- 700 gpm (2646 L/M) @ 200 psi (13.8 bar)
- 500 gpm (1893 L/M) @ 250 psi (17.2 bar)
PSM 1250
- 1250 gpm (4731 L/M) @ 150 psi (10.3 bar)
- 875 gpm (3312 L/M) @ 200 psi (13.8 bar)
- 625 gpm (2365 L/M) @ 250 psi (17.2 bar)
PSM 1500
- 1500 gpm (5678 L/M) @ 150 psi (10.3 bar)
- 1050 gpm (3974 L/M) @ 200 psi (13.8 bar)
- 750 gpm (2839 L/M) @ 250 psi (17.2 bar)
PSM 1750
- 1750 gpm (6624 L/M) @ 150 psi (10.3 bar)
- 1225 gpm (4637 L/M) @ 200 psi (13.8 bar)
- 875 gpm (3312 L/M) @ 250 psi (17.2 bar)
PSM 2000
- 2000 gpm (7570 L/M) @ 150 psi (10.3 bar)
- 1400 gpm (5299 L/M) @ 200 psi (13.8 bar)
- 1000 gpm (3785 L/M) @ 250 psi (17.2 bar)
- 5″ NPT or weld discharge
- 6″ NPT or weld flange suction
- 1610 or 1710 full round yokes standard
- Air shift
MECHANICAL SEAL
- Made with silicon carbide stationary face, extremely hard and heat dissipative resisting wear and dry running damage. Optional injection packing is available.
MAGNATRANS™ GEARBOX
- 19,230 ft. lb. rating helical cut gears for smooth, quiet operation. AutoCool™ means no freezing problems. Chamfered sliding clutch for positive engagements.
660 lbs. (300 kg)
29.45″ (748mm) L x 17.72″ (450mm) W x 30.55″ (776mm) H
- Aerial
- Tanker
- Pumper
- Airports
- Refineries
- Urban settings
