ZSE 2500-3000
Part Number: zse2500
ZSE 2500-3000
Part Number: zse2500
- Single Stage
- Centrifugal Single Suction Impeller
- Engine Mounted
Documents & Downloads
IGS 3D Files
Performance Curves
Operation Manuals
Sales Flyers
Performance
ZSE 2500
- 2500 gpm (9463 L/M) @ 150 psi (10.3 bar)
- 2500 gpm (9463 L/M) @ 165 psi (11.3 bar)
- 1750 gpm (6624 L/M) @ 200 psi (13.8 bar)
- 1250 gpm (4732 L/M) @ 250 psi (17.2 bar)
Using 1 – 8″ or 3 – 6″ suction hose
Rated at 2500 gpm for NFPA 1901 fire pump application
ZSE 3000
- 3000 gpm (11,356 L/M) @ 150 psi (10.3 bar)
- 1500 gpm (5678 L/M) @ 250 psi (17.2 bar)
Using 2 – 8″ or 4 – 6″ suction hose
Rated at 3000 gpm for NFPA 1901 fire pump application
Features
- Mechanical Seal
- SAE #1 Housing
- SAE 14″ Flywheel
- Mega transmission
- 6″ weld discharge
- 8″ weld flange suction
Engine
N/A
Weight
605 lbs. (274 kg)
Dimensions
24″L x 27″W x 31″H
Applications
- Industrial
- Chemical
- Aerial
- ARFF
- Fire Boat
Options
N/A
Technology
N/A
