LSE 500-1000 Direct Mount
Part Number: lse500
LSE 500-1000 Direct Mount
Part Number: lse500
Single Stage, Centrifugal, Single Suction Impeller, 2 Gear Gearcase, Engine Mounted
Documents & Downloads
DWG Drawings
Performance Curves
Operation Manuals
Sales Flyers
Performance
LSE 500
- 500 gpm (1893 L/M) @ 150 psi (10.3 bar)
- 350 gpm (1325 L/M) @ 200 psi (13.8 bar)
- 250 gpm (946 L/M) @ 250 psi (17.2 bar)
LSE 750
- 750 gpm (2839 L/M) @ 150 psi (10.3 bar)
- 525 gpm (1987 L/M) @ 200 psi (13.8 bar)
- 375 gpm (1419 L/M) @ 250 psi (17.2 bar)
LSE 1000
- 1000 gpm (3785 L/M) @ 150 psi (10.3 bar)
- 700 gpm (2646 L/M) @ 200 psi (13.8 bar)
- 500 gpm (1893 L/M) @ 250 psi (17.2 bar)
Features
- Vertically split, cast iron bronze fitted pump casing
- Impellers opposed design to eliminate end thrust
- Broached impeller (not keyed) for longer life
- Oversized, deep groove radial type bearings for longer life
- 10-tooth splined shaft for durability
- 4″ NPT discharge
- 5″ or 6″ weld flange suction
- Uses standard SAE engine adapter
Engine
N/A
Weight
235 lbs. (107 kg)
Dimensions
16″L x 17″W x 24″H
Applications
- Fire Boat
- Mini Pumper
- Pumper
- Wildland/Attack Fire
Options
N/A
Technology
N/A
