Available with Manual or Electric Control Options
Darley Air-Powered Primer










Darley Air-Powered Primer
Available with Manual or Electronic Control Options
Darley’s new air-powered priming system is designed to utilize the air power from the air brakes system on fire trucks, offering a reliable and efficient solution for fire departments.
Features
- High-Corrosion Resistance – Brass and stainless-steel components allow this unit to stand up to harsh conditions in both fresh and saltwater applications.
- Few Moving Parts – This system utilizes simple components to make any maintenance quick and easy.
- Control Options – Comes with manual and electronic control options to fit your needs and style. The available control systems come as plug-and-play solutions for easy installation.
- 12V or 24V – Darley also offers a 12V and 24V rotary vane primer for applications without compressed air.
- Any air primer application requires a compressor capable of outputting at least 15.6 CFM.
- Primer can be used with pumps rated 2000 GPM and smaller.
- NFPA compliant
Weight
- 10 lbs.
Base Model Manual Panels
Available with Manual or Electronic Control Options
Darley’s new air-powered priming system is designed to utilize the air power from the air brakes system on fire trucks, offering a reliable and efficient solution for fire departments.
Features
- High-Corrosion Resistance – Brass and stainless-steel components allow this unit to stand up to harsh conditions in both fresh and saltwater applications.
- Few Moving Parts – This system utilizes simple components to make any maintenance quick and easy.
- Control Options – Comes with manual and electronic control options to fit your needs and style. The available control systems come as plug-and-play solutions for easy installation.
- 12V or 24V – Darley also offers a 12V and 24V rotary vane primer for applications without compressed air.
- Any air primer application requires a compressor capable of outputting at least 15.6 CFM.
- Primer can be used with pumps rated 2000 GPM and smaller.
- NFPA compliant
Weight
- 10 lbs.
Base Model Manual Panels
AP04406 | Manual push to prime without lift gauge
AP04405 | Manual push to prime with lift gauge
Optional Electronic Panels
AP04401 | 12V Autoprime with lift gauge
AP04402 | 12V Autoprime without lift gauge
AP04403 | 24V Autoprime with lift gauge
AP04404 | 24V Autoprime without lift gauge
